Werma 784EX Revolving Signal Beacon
The Werma 784 Ex Revolving Signal Beacon is suitable for Zone 1, 2, 21 and 22.
The Werma 784 Ex Revolving Signal Beacon is suitable for Zone 1, 2, 21 and 22. The 784Ex Revolving Signal Beacon has a flame-proof enclosure and is saltwater-proof.
The Werma 784Ex has 3 fresnel lenses that effect the light convergence and ensure optimized visibility. It has a low rotation rate and a high life duration due to the low wear wheel and disc drive.
| Interface | Screwable connection max. 2.5 mm2 single wire |
|---|---|
| Rotation rate | 60 U/min |
| Color | yellow |
| Cable entry | Cable diameter 5 – 13 mm, Cable gland M20 x 1.5 |
| Life duration | Min. 5,000 h (bulb: dependent on illuminant) |
| Dimensions | 195 x 305 mm |
| Ingress protection | IP66 |
| Voltage | 115V |
| Voltage type | AC/DC |
| Current consumption | 350 mA |
| Housing | Aluminium, salt-water proof |
| Dome material | Borosilicate glass |
| Protection ignition | Ex II 2G Ex de IIC T4 |
| Type of signal | Rotating |
| Lamp | Halogen G 6.35 35 W 12V/24V |
| Approvals | PTB 06 ATEX 1039 |
