| SPL | 105dB +/-3dB @ 1w @ 1m (Pink), 119dB +/-3dB @ 25w @ 1m (Rated) |
|---|---|
| Rated power | 25 Watts RMS |
| 70v line tappings | (z=196 Ohms /392 Ohms /, 25w / 12.5w / 6w / 2w tappings, 816.67 Ohms / 2.45k Ohms) |
| 100v line tappings | (z=400 Ohms /800 Ohms /, 1.67k Ohms / 5k Ohms), 25w / 12.5w / 6w / 2w tappings |
| Low impedence | 8 Ohm or 16 Ohm |
| Dispersion | 130° @ 1kHz & 32° @ 4kHz |
| Frequency range | 300Hz to 8000 Hz |
| DC Line monitoring | 2.2µF Capacitor (Transformer), 470µF Capacitor (Impedance) |
| Ingress protection | EN60529: IP66 |
| Enclosure material | 316L Stainless Steel |
| Enclosure finish | Chromated & powder coated |
| Color | Red (RAL3000) |
| Cable entries | 3 x M20 x 1.5mm |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Grounding stud | M5 |
| Operating temperature | -50° to +70°C [-58° to +158°F] |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight | 6.25kg/13.75lbs |
