| Maximum output | 115dB(A) @ 1 m +/- 3dB [109dB(A) @ 10ft/3m +/- 3dB] |
|---|---|
| Nominal output | 110dB(A) @ 1m +/- 3dB [106dB(A) @ 10ft/3m] +/- 3dB |
| No. of tones | 64 (UKOOA / PFEER compliant) |
| No. of stages | 4 |
| Volume control | Full range |
| Effective range | 125m/410ft @ 1KHz |
| Voltage DC | 12Vdc (11.5-14Vdc), 24Vdc (20-28Vdc), 48Vdc (42-54Vdc) |
| Voltage AC | 230vac (220-240vac) |
| Stage switching | AC units: common supply line, DC units: negative or positive |
| Energy | 5 Joules (5Ws) |
| Flash rates | 1.5Hz flash (90 fpm), 1Hz flash (60 fpm), Double flash (120 fpm) |
| Eff. Intensity cd | 143 cd* – measured ref. to I.E.S., 250 cd – calculated from energy (J) |
| Peak Candela | 46,976 cd* – measured ref. to I.E.S., 500,000 cd – calculated from energy (J) |
| Lens colours | Amber, Blue, Clear, Green, Magenta, Red & Yellow |
| Tube life | Emissions are reduced to 70% after 5 million flashes |
| Safety Integrity Level | SIL1 and SIL2 Route 2H IEC61508 (2010) |
| Ingress protection | EN60529: IP66 |
| Enclosure material | 316L Stainless Steel |
| Enclosure colour | Red |
| Enclosure finish | Chromate & powder coated finish |
| Cable entries | 3 x M20x1.5mm, Stopping plugs included |
| Measurable gases | Stainless Steel |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG), Pluggable & duplicated terminals |
| Line monitoring | Blocking diode for reverse polarity monitoring, Blocking diode included, Diode polarized for use in supervised circuits, EOL Min. 500 Ohm 2w, or 3k3 Ohm 0.5w resistor, or diode (DC versions) can be fitted |
| Ground/Earth stud | M5 |
| Installation temp | -50° to +70°C (-58°F to +158°F) |
| Storage temperature | -50° to +70°C (-58°F to +158°F) |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight | 7.45kg/16.42lbs |
