| Energy | 10 Joules (10Ws) |
|---|---|
| Flash rate | 1Hz (60 fpm) |
| Peak Candela | 1,000,000 cd – calculated from energy (J), 87,590 cd* – measured ref. to I.E.S. |
| Eff. Intensity cd | 380 cd* – measured ref. to I.E.S., 500 cd – calculated from energy (J) |
| Lens colours | Amber, Blue, Clear, Green, Magenta, Red & Yellow |
| Voltage DC | 12Vdc; 24vdc; 48Vdc |
| Voltage AC | 115Vac; 230Vac |
| Ingress protection | IP66/67 Type 4/4X/13 |
| Enclosure material | High impact UL94 V0 & 5VA FR ABS |
| Enclosure colour | Grey (RAL7038) or Red (RAL3000) |
| Dome material | Borosilicate glass |
| Lens colour filter | Field replaceable UV stable PC |
| Lens guard | 316 (A4) Stainless steel |
| Cable entries | supplied with blanking plug |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring | Diode polarized for use in supervised circuits |
| Operating temperature | -40 to +66°C [-40° to +151°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 95% at 20°C [68°F] |
| MTBF DC | 253.68 years / 2,222,222 hours – MIL 217 |
| MTBF AC | 279.79 years / 2,450, 980 hours – MIL 217 |
| Weight | 1.48kg/3.25Ibs |
