| Operating Voltage | 14-30V dc |
|---|---|
| Reverse voltage | 60V max. |
| Current | 18 to 22mA |
| Output | Typical at 150mm:Red 190 lux, Amber 150 lux, Green 250 lux, Blue 150 lux, White 300 lux |
| Ingress protection | Front IP66 – Rear IP20 – see accessories foroptional IP65 rear sealing assembly. |
| Rating | Continuous |
| Housing Material | Nylon 6 |
| Lens material | Polycarbonate |
| Mounting | Panel mount – 22.5mm |
| Terminals | Screw clamp for 1.5mm2 |
| Operating temperature | 20 to 60°C [68°to 140°F] |
| Storage temperature | 40 to 85°C [104° to 185°F] |
| Relative Humidity | 5 to 95% non condensing |
| Weight | 20g / 0.04Ibs |
