| Nominal output | 110dB(A) @ 1m +/- 3dB [101dB(A) @ 10ft/3m] |
|---|---|
| No. of tones | 3 |
| Stage switching | AC voltage via live supply, DC voltage via negative |
| Volume control | On board potentiometer |
| Voltage DC | 10-30V dc/ac |
| Voltage AC | 40-260V dc/ac |
| Ingress protection | GPH3: IP66 (UL Type 4/4X/13), GPH4: IP54 (UL Type 13/3R) |
| Housing Material | High impact UL94 V0 (f1) PC |
| Color | Grey (RAL7038) |
| Cable entries | 2 x M20 clearance |
| Terminals | 22 – 12AWG (0.5-3mm2) |
| Operating temperature | -25 to +55°C [-13° to +131°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 90% at 20°C [68°F] |
| Weight | 0.40Kg/0.88Ibs |
