| SPL | 105dB +/-3dB @ 1w @ 1m (Pink), 119dB +/-3dB @ 25w @ 1m (Rated) |
|---|---|
| Rated power | 25 Watts RMS |
| Low impedence | 8 Ohm or 16 Ohm |
| Dispersion | 130° @ 1kHz & 32° @ 4kHz |
| Frequency range | 300Hz to 8000 Hz |
| DC Line monitoring | 2.2µF Capacitor (Transformer version), 470µF Capacitor (Impedance version) |
| Ingress protection | IP66/67 |
| Enclosure material | GRP |
| Color | (others available on request), RAL3000 Red |
| Horn flare | & 5VA FR ABS (Red), High impact UL94 V0 |
| Cable entries | Dual M20 ISO |
| Terminals | 0.5 to 4.0mm2 cables |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight | 70/100V line: 4.3kg/9.46Ibs Low imp.: 3.95kg/8.59Ibs |
