| SPL | 102dB +/-3dB @ 1w @ 1m (Pink), 113dB +/-3dB @ 15w @ 1m (Rated) |
|---|---|
| Rated power | 15 Watts RMS |
| Low impedence | 8 Ohm or 16 Ohm |
| Dispersion | 120° @ 1kHz & 32° @ 4kHz |
| Frequency range | 400Hz to 8000 Hz |
| DC Line monitoring | 2.2µF Capacitor (Transformer), 470µF Capacitor (Low impedance) |
| Ingress protection | IP66/67 |
| Housing Material | GRP |
| Color | (others available on request), RAL3000 Red |
| BExL15 flare | & 5VA FR ABS (Red), High impact UL94 V0 |
| Cable entries | Dual M20 ISO |
| Terminals | 0.5 to 4.0mm2 cables. |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight | 70/100V line: 3.8kg/8.36Ibs Low imp.: 3.45kg/7.59Ibs |
