| Maximum output | 121dB(A) @ 1 metre [112dB(A) @ 10ft/3m] |
|---|---|
| Nominal output | 117dB(A) @ 1m +/- 3dB – Tone 2 [108dB(A) @ 10ft/3m] |
| No. of tones | 45 (UKOOA/PFEER compliant) |
| No. of stages | 3 |
| Volume control | – Tone 2, Max. 117dB(A); Min. 111dB(A) |
| Effective range | 200m/656ft @ 1KHz |
| Voltage DC | 24Vdc (10-30Vdc); 48Vdc |
| Voltage AC | 115Vac; 230Vac |
| Ingress protection | IP rating per EN60079-0:IP64, IP rating per EN60529:IP66, Type rating per UL50E/NEMA250:4/4X/13 |
| Enclosure material | UL94V0 GRP (PPS) & ABS |
| Cable entries | Dual M20x1.5 or 1/2″NPT |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring | Blocking diode included, EOL can be factory fitted |
| Operating temperature | -20 to +55°C [-4° to +131°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 90% at 20°C [68°F] |
| Weight | DC: 2.75kg/6.05Ibs AC: 3.25kg/7.15Ibs |
