| SPL | 111dB +/-3dB @ 1w @ 1m (Pink), 124dB +/-3dB @ 25w @ 1m (Rated) |
|---|---|
| Rated power | 25 Watts RMS |
| Low impedence | 8 Ohm or 16 Ohm |
| Dispersion | 130° @ 1kHz & 32° @ 4kHz |
| Frequency range | 300Hz to 8000 Hz |
| DC Line monitoring | (Transformer version), 2.2µF Capacitor |
| Ingress protection | IP rating per EN60079-0:IP64, IP rating per EN60529:IP66, Type rating per UL50E/NEMA250:4/4X/13 |
| Enclosure material | UL94V0 GRP (PPS) & ABS |
| Cable entries | Dual M20x1.5 or 1/2″NPT |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Operating temperature | -20 to +55°C [-4° to +131°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 90% at 20°C [68°F] |
| Weight | Low impedance: 2.75kg/6.05Ibs, Transformer: 3.25kg/7.15Ibs |
