| Maximum output | 116dB(A) @ 1 metre [107dB(A) @ 10ft/3m] |
|---|---|
| Nominal output | 113dB(A) @ 1m +/- 3dB – Tone 2 [104dB(A) @ 10ft/3m] |
| No. of tones | 45 (UKOOA/PFEER compliant) |
| No. of stages | 3 |
| Volume control | Max. 113dB(A) Min. 105dB(A) – Tone 2 |
| Effective range | 100m/328ft @ 1KHz |
| Source | Array of 4 x High Power Cree LEDs |
| Modes | 1.5Hz flash (90 fpm), 1Hz flash (60 fpm), 2Hz flash (120 fpm), Double strike flash, High Power Steady, Low Power Steady, Triple strike flash |
| Eff. Intensity cd | 160 cd – 1Hz flash, 87 cd – High Power Steady |
| Voltage | 24V dc; 115V ac; 230V ac (LED beacon), 24Vdc; 48Vdc; 115Vac; 230Vac |
| Ingress protection | IP rating per EN60079-0:IP64, IP rating per EN60529:IP66, Type rating per UL50E/NEMA250:4/4X/13 |
| Enclosure material | UL94V0 GRP (PPS) & ABS |
| Lens material | Borosilicate glass dome with PC prismatic lens cover. |
| Guard | Stainless Steel dome guard as standard |
| Cable entries | Dual M20x1.5 or 1/2″NPT |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring | Blocking diode included, EOL can be factory fitted |
| LED life | 60,000 hours |
| Operating temperature | -20 to +55°C [-4° to +131°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 90% at 20°C [68°F] |
| Weight | DC: 3.00Kg/6.6Ibs AC: 3.50kg/7.7Ibs |
