| Maximum output | 116dB(A) @ 1 metre [107dB(A) @ 10ft/3m] |
|---|---|
| Nominal output | 112dB(A) @ 1m +/- 3dB – Tone 2 [103dB(A) @ 10ft/3m] |
| No. of tones | 64 (UKOOA / PFEER compliant) |
| No. of stages | 4 |
| Volume control | Adjustable -12dB(A) [Tone 2] |
| Effective range | 125m/410ft @ 1KHz |
| Synchronization | (Alarm horn sounder), Synchronised 1Hz flash rate (DC voltage versions) |
| Energy | 10 Joules (10Ws) |
| Flash rate | 1Hz (60 fpm) |
| Peak Candela | 1,000,000 cd – calculated from energy (J), 101,784 cd* – measured ref. to I.E.S. |
| Eff. Intensity cd | 288.8 cd* – measured ref. to I.E.S., 500 cd – calculated from energy (J) |
| Lens colours | Amber, Blue, Clear, Green, Magenta, Red & Yellow |
| Voltage DC | 24V dc, 48V dc |
| In rush | 2.3A for |
| Voltage AC | 115Vac, 230Vac |
| Ingress protection | IP rating per EN60529:IP66, Type rating per UL50E/NEMA250:4/4X/3R/13 |
| Enclosure material | Marine grade LM6 aluminum alloy |
| Enclosure colour | Red or Grey, custom colours available on request |
| Lens material | Borosilicate glass dome with PC prismatic lens cover |
| Guard | Stainless Steel dome guard as standard |
| Cable entries | |
| Measurable gases | Optional brass, nickel plated or stainless steel, Stopping plug included |
| Ground/Earth stud | M5 |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring | Blocking diode included, EOL can be factory fitted |
| Operating temperature | -40 to +50°C [-40° to +122°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 00%, 95 |
| Weight | DC: 4.00kg/8.82Ibs AC:4.50kg/9.92lbs |
