| Energy | 5 Joules (5Ws) |
|---|---|
| Source | Xenon Strobe |
| Modes | 1Hz flash (60 fpm) |
| Eff. Intensity cd | 18.18 cd – UL1971, 250 cd – calculated from energy (J) |
| Peak Candela | 500,000 cd – calculated from energy (J) |
| Synchronization | Flash rates synchronise for a minimum of 2 hours per UL1971 |
| Voltage | 24Vdc – 20-28Vdc |
| Ingress protection | IP rating per EN60529:IP66, Type rating per UL50E/NEMA250:4/4X/3R/13 |
| Enclosure material | Marine grade LM6 aluminum alloy |
| Enclosure colour | Red |
| Lens colours | Clear |
| Lens material | Borosilicate glass dome |
| Cable entries | |
| Measurable gases | Nickel Plated Brass plugs included – brass or stainless steel optional |
| Mounting | Conduit mount via 3/4″ NPT entry, Surface mount via supplied lug pack (user installed) |
| Ground/Earth stud | M5 |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring | Blocking diode included, EOL can be factory fitted |
| Operating temperature | -40 to +50°C [-40° to +122°F] |
| Storage temperature | -40 to +70°C [-40° to +158°F] |
| Relative Humidity | 00%, 95 |
| Weight | 1.5kg/3.31Ibs |
