| Product version A SPL | 104dB +/-3dB @ 1W @ 1m (Pink), 118dB +/-3dB @ 25W @ 1m (Rated), 123dB(A) @ 1 m at 1.3Khz (Max) |
|---|---|
| Product version D SPL | 108dB(A) @ 1 m at 1.3Khz (Max), 89dB +/-3dB @ 1W @ 1m (Pink), 97dB +/-3dB @ 25W @ 1m (Rated) |
| Rated power | 25 Watts RMS |
| Low impedance | 8 Ohm or 16 Ohm |
| Directivity Index | 7.6 @ 1kHz & 17.6 @ 4kHz [dB on-axis] |
| Frequency range | 300Hz to 8000 Hz |
| DC Line monitoring | 2.2µF Capacitor (Transformer ), 470µF Capacitor (Low impedance) |
| Ingress protection | EN60529: IP66/67, UL50E / NEMA250: 4 / 4X / 3R / 13 |
| Enclosure material | Marine grade LM6 aluminium alloy |
| Enclosure colour | Red or Grey, custom colours available on request |
| Enclosure finish | Chromate & powder coated finish |
| Cable entries | Thread adaptors available |
| Measurable gases | Brass, Nickel Plated or Stainless Steel |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG), Duplicated terminals |
| Grounding stud | M5 |
| Product A Installation temp | CEC/IECEx/ATEX: -55° to +75°C [-67° to +167°F], NEC: -55° to +85°C [-67° to +185°F] |
| Product D Installation temp | NEC Class Div: -40° to +70°C [-40° to +158°F], NEC Class Zone, CEC Class Div/Zone: -55° to +75°C [-67° to +167°F] |
| Storage temperature | -55° to +85°C [-67° to +185°F] |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight | 100V/70V line: 4.5kg/9.9Ibs, Low imp.: 4.2kg/9.1Ibs |
