| Maximum output | 117dB(A) @ 1 metre [108dB(A) @ 10ft/3m] |
|---|---|
| Lens colours | Amber, Blue, Clear, Green, Magenta, Red & Yellow |
| No. of tones | 32 (UKOOA / PFEER compliant) |
| Volume control | Max. 110dB(A); Min. 72dB(A) – Tone 2 |
| Effective range | 100m/328ft @ 1KHz |
| Voltage DC | 12Vdc; 24vdc; 48Vdc |
| Voltage AC | 115Vac; 230Vac |
| Energy | 5 Joules (5Ws) |
| Flash rate | 1Hz (60 fpm) |
| Peak Candela | 39,463 cd* – measured ref. to I.E.S., 500,000 cd – calculated from energy (J) |
| Eff. Intensity cd | 120 cd* – measured ref. to I.E.S., 250 cd – calculated from energy (J) |
| Nominal output | 110dB(A) @ 1m +/- 3dB – Tone 2 [101dB(A) @ 10ft/3m] |
| Ingress protection | IP66/67 |
| Tube life | Emissions are reduced to 70% after 5 million flashes |
| Enclosure material | LM6 Aluminium, Marine grade copper free |
| Enclosure finish | Chromate & powder coated |
| Horn material | High impact UL94 V0 & 5VA FR ABS (Red) |
| Cable entries | Dual M20 ISO (one stopping plug included) |
| Terminals | 0.5 – 2.5mm2 (20-14 AWG) |
| Grounding stud | M5 |
| Temperature range | -50° to +70°C (-58°F to +158°F) |
| Relative Humidity | 95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| MTBF AC | 66.56 years / 583,091 hours – MIL217 |
| Weight | DC: 4.80kg/10.56Ibs AC: 5.00kg/11Ibs |
