| Maximum output |
116dB(A) @ 1 metre [107dB(A) @ 10ft/3m] |
|---|---|
| Nominal output |
112dB(A) @ 1m +/- 3dB – Tone 2 [103dB(A) @ 10ft/3m] |
| No. of tones |
64 (UKOOA / PFEER compliant) |
| No. of stages |
4 |
| Volume control |
Adjustable -12dB(A) [Tone 2] |
| Effective range |
125m/410ft @ 1KHz |
| Synchronization |
Automatic synchronisation (Alarm horn sounder) , Flash rates synchronise for a minimum of 2 hours per UL1971 |
| Source |
Xenon Strobe |
| Modes |
1Hz flash (60 fpm) |
| Peak Candela |
1 , 000 , 000 cd – calculated from energy (J) |
| Eff. Intensity cd |
63.73 cd UL1971 Public mode fire , 500 cd – calculated from energy (J) |
| Voltage |
24V dc [20-28V dc] |
| In rush |
2.3A for 9ms |
| Ingress protection |
IP rating per EN60529:IP66 , Type rating per UL50E/NEMA250:4/4X/3R/13 |
| Enclosure material |
Marine grade LM6 aluminum alloy |
| Enclosure colour |
Red |
| Lens material |
Borosilicate glass |
| Cable entries |
|
| Measurable gases |
Nickel plated brass plugs included |
| Ground/Earth stud |
M5 |
| Terminals |
0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring |
Blocking diode included , EOL can be factory fitted |
| Operating temperature |
-40 to +50°C [-40° to +122°F] |
| Storage temperature |
-40 to +70°C [-40° to +158°F] |
| Relative Humidity |
00% , 95 |
| Weight |
4.00kg/8.82Ibs |
