| Energy |
5 Joules (5Ws) |
|---|---|
| Flash rate |
1Hz (60 fpm) |
| Peak Candela |
33 , 410 cd* – measured ref. to I.E.S. , 500 , 000 cd – calculated from energy (J) |
| Eff. Intensity cd |
250 cd – calculated from energy (J) , 94.78 cd* – measured ref. to I.E.S. |
| Lens colours |
Amber , Blue , Clear , Green , , Magenta , Red & Yellow |
| Voltage DC |
24vdc; 48vdc |
| Voltage AC |
115Vac; 230Vac |
| Ingress protection |
IP rating per EN60529:IP66 , Type rating per UL50E/NEMA250:4/4X/3R/13 |
| Enclosure material |
Marine grade LM6 aluminum alloy |
| Enclosure colour |
Red or Grey , custom colours available on request |
| Lens material |
Borosilicate glass dome with PC prismatic lens cover |
| Guard |
Stainless Steel dome guard as standard |
| Cable entries |
|
| Measurable gases |
Nickel plated brass plugs included |
| Ground/Earth stud |
M5 |
| Terminals |
0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring |
Blocking diode included , EOL can be factory fitted |
| Operating temperature |
-40 to +50°C [-40° to +122°F] |
| Storage temperature |
-40 to +70°C [-40° to +158°F] |
| Relative Humidity |
00% , 95 |
| Weight |
DC: 1.5kg/3.31Ibs AC:1.75kg/3.86lbs |
