| Maximum output |
[103dB(A) @ 10ft/3m +/- 3dB] ,[105dB(A) @ 10ft/3m +/- 3dB] ,Default power level: 112dB(A) @ 1 m +/- 3dB ,High power level: 114dB(A) @ 1 m +/- 3dB |
|---|---|
| Nominal output |
[100dB(A) @ 10ft/3m] +/- 3dB ,[98dB(A) @ 10ft/3m] +/- 3dB ,Default power level: 107dB(A) @ 1m +/- 3dB ,High power level: 109dB(A) @ 1m +/- 3dB |
| No. of tones |
64 (UKOOA / PFEER compliant) |
| No. of stages |
4 |
| Volume control |
Full range |
| Effective range |
125m/410ft @ 1KHz |
| Voltage DC |
24Vdc (20-28Vdc) |
| Voltage AC |
110-120Vac, 220-240Vac |
| Stage switching |
AC units: common supply line ,DC units: negative or positive |
| Energy |
10 Joules (10Ws) |
| Flash rates |
Option 1: 1Hz (60 fpm) ,Option 2: 1.5Hz (90 fpm) ,Option 3: Double Strike |
| Peak Candela |
1,000,000 cd – calculated from energy (J) ,85,544 cd* – measured ref. to I.E.S. |
| Eff. Intensity cd |
260 cd* – measured ref. to I.E.S. ,500 cd – calculated from energy (J) |
| Lens colours |
Amber, Blue, Clear, Green, Magenta, Red & Yellow |
| Tube life |
Emissions reduced to 70% > 5 million flashes |
| Safety Integrity Level |
SIL1 and SIL2 Route 2H IEC61508 (2010) |
| Ingress protection |
EN60529: IP66/67 ,UL50E / NEMA250: 4 / 4X / 3R / 13 |
| Enclosure material |
Chromated & powder coated – corrosion proof ,Marine grade aluminium LM6 – copper free |
| Enclosure colour |
Red or Grey, custom colours available on request |
| Cable entries | |
| Terminals |
0.5 – 2.5mm2 (20-14 AWG) Pluggable, duplicated terminals |
| Grounding stud |
M5 |
| Line monitoring |
Blocking diode included. EOL Min. 500 Ohm 2W, or 3k3 Ohm 0.5W resistor or diode (DC versions) can be fitted |
| Installation temp |
-55 to +85°C [-67° to +185°F] |
| Storage temperature |
-55 to +85°C [-67° to +185°F] |
| Relative Humidity |
95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Vibration test |
35Hz for a duration 4Hr (UL464) |
| Jarring test |
3ft/lb Energy (UL464) |
| Impact test |
3x 5lb (UL464) |
| Weight |
5.0kg/10.10lbs |
