| Source |
Xenon Strobe |
|---|---|
| Energy |
10 Joules |
| Modes |
1.3Hz flash (80 fpm) ,1.5Hz flash (90 fpm) ,1Hz flash (60 fpm) ,Double flash (120 fpm) |
| Eff. Intensity cd |
86.37 cd UL1971 Public mode fire |
| Peak Intensity cd |
1,000,000 cd |
| Synchronization |
Flash rates synchronize for a minimum of 2 hours per UL1971 |
| Voltage |
24V dc (20-28V dc) |
| Ingress protection |
IP rating per EN60529:IP66/67 ,Type rating per UL50E/NEMA250:4/4X/3R/13 |
| Enclosure material |
Marine grade LM6 aluminum alloy |
| Enclosure Color |
Red (RAL3000) |
| Lens material |
High impact Borosilicate glass |
| Cable entries | |
| Measurable gases |
Nickel plated brass plugs included |
| Terminals |
0.5 – 2.5mm2 (20-14 AWG) |
| Line monitoring |
Blocking diode included ,EOL can be factory or user installed |
| Operating temperature |
-55 to +80°C [-67° to +176°F] |
| Storage temperature |
-55 to +80°C [-67° to +176°F] |
| Relative Humidity |
95% – Additional tropicalisation is recommended for applications where both high relative humidity and high ambient temperatures exist |
| Weight |
3.2kg/7.1Ibs |
