| Warranty |
10 year |
|---|---|
| Flash rate |
1Hz |
| Protocol voltage |
5 to 9V peak to peak |
| Selectable volume(s) |
55-75dB (A) ,75-91dB (A) |
| Tone(s) |
2 |
| Color |
White |
| Finish |
Semi-gloss |
| Materials housing |
Polycarbonate |
| Height |
38mm (1.5in) |
| Weight |
160g (0.35lbs) |
| Standards |
EN 54-17 ,EN 54-3 |
| Diameter |
115mm (4.53in) |
| Approvals |
CPR ,FG |
| Terminal functions L2 |
+L2 Loop in & out positive, double terminal |
| Terminal functions L1 in |
-L1 in Loop in & out, double terminal |
| Terminal functions +R |
+R Remote indicator positive connection |
| Terminal functions -R |
-R Remote indicator negative connection |
| Polarity |
L1 & L2 are polarity sensitive |
| Battery powered |
No |
| Maximum sound output tone |
91dB (A) |
| Storage temperature (max) |
60°C |
| Storage temperature |
-20 to 60°C |
| Quiescent current |
300μA |
| Quiescent current tested at |
24V dc |
| Supply voltage (min) |
17V dc |
| Supply voltage (max) |
28V dc |
| Supply voltage (Vmin-Vmax) |
17 to 28V dc |
| Loop powered |
Yes |
| Storage temperature (min) |
-20°C |
| Protocol voltage (min) |
5V |
| Protocol voltage (max) |
9V |
| Humidity (max) |
95% RH |
| Humidity (min) |
0% RH |
| Humidity |
0% to 95% (no condensation or icing) |
| Humidity Note |
no condensation or icing |
| Operating temperature (max) |
60°C (140°F) |
| Operating temperature (min) |
-20°C (-4°F) |
| Operating temperature |
-20 to 60°C (-4 to 140°F) |
| Power-up surge current |
01-02-23 |
| IP rating Value |
IP21C |
