Crowcon 20/20ML – Mini UV/IR Flame Detector

The Crowcon 20/20ML is a compact, lightweight but rugged UV/IR Flame Detector for general purpose (non-Ex approved) areas. The Crowcon 20/20ML Flame Detector can detect hydrocarbon-based fuel and gas fires, hydroxyl and hydrogen fires, as well as metal and inorganic fires at distances up to 15m (50ft).

The UV sensor of the 20/20ML – Mini UV/IR Flame Detector incorporates a special logic circuit that helps prevent false alarms caused by solar radiation. When the UV and the IR sensor simultaneously detect radiant energy, they will trigger an alarm.

Features
UV/IR Dual-Sensor
High-speed response
50 msec response to saturated signal
Large field of view (100° horizontal/vertical)
User programmable functions configurable via software from a PC or handheld device
Immune to false Alarms (solar blind)
Automatic and manual Built-In-Test (BIT)
Standard 4-wire connection
4-20mA source (3-4 wires) configuration
RS-485 modbus compatible
MTBF minimum 100,000 hours.
